2- 14 Keysight B2961A/B2962A SCPI Command Reference, Edition 6
Subsystem Command Summary
Setting Source Output and Measurement
[:SOUR[c]]:ARB:CURR:TRI:STAR[:LE
V] level
[:SOUR[c]]:ARB:VOLT:TRI:STAR[:LE
V] level
[:SOUR[c]]:ARB:CURR:TRI:STAR[:LE
V]?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:TRI:STAR[:LE
V]?
[DEFault|MINimum|MAXimum]
Set the start level of the triangle
waveform output.
level=MINimum|MAXimum|DEFault|
minimum to maximum source value, in A
or V. See
“Source Output Ranges” on
page 2-36.
0
[:SOUR[c]]:ARB:CURR:TRI:STAR:TIM
E time
[:SOUR[c]]:ARB:VOLT:TRI:STAR:TIM
E time
[:SOUR[c]]:ARB:CURR:TRI:STAR:TIM
E?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:TRI:STAR:TIM
E?
[DEFault|MINimum|MAXimum]
Set the start time of the triangle waveform
output. Waveform period must not exceed
1000 seconds.
time=MINimum|MAXimum|DEFault|0 to
1000 seconds.
0
[:SOUR[c]]:ARB:CURR:TRI:TOP[:LEV
] level
[:SOUR[c]]:ARB:VOLT:TRI:TOP[:LEV
] level
[:SOUR[c]]:ARB:CURR:TRI:TOP[:LEV
]?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:TRI:TOP[:LEV
]?
[DEFault|MINimum|MAXimum]
Set the top level of the triangle waveform
output.
level=MINimum|MAXimum|DEFault|
minimum to maximum source value, in A
or V. See
“Source Output Ranges” on
page 2-36.
0
[:SOUR[c]]:ARB:CURR:UDEF:BOST
list
[:SOUR[c]]:ARB:VOLT:UDEF:BOST
list
[:SOUR[c]]:ARB:CURR:UDEF:BOST?
[:SOUR[c]]:ARB:VOLT:UDEF:BOST?
Sets the trigger output status for each
point of the user defined waveform.
list: List of the trigger output status.
Maximum of 100000 data can be set to
list. Each data must be separated by a
comma.
0
Command Summary Reset setting
