2- 16 Keysight B2961A/B2962A SCPI Command Reference, Edition 6
Subsystem Command Summary
Setting Source Output and Measurement
[:SOUR[c]]:ARB:CURR:UDEF[:LEV]
list
[:SOUR[c]]:ARB:VOLT:UDEF[:LEV]
list
[:SOUR[c]]:ARB:CURR:UDEF[:LEV]?
[:SOUR[c]]:ARB:VOLT:UDEF[:LEV]?
Sets the current or voltage output data for
each point of the user defined waveform.
list: List of the current or voltage output
data. Maximum of 100000 data can be set
to list. Each data must be separated by a
comma.
0
[:SOUR[c]]:ARB:CURR:UDEF[:LEV]:A
PP append_list
[:SOUR[c]]:ARB:VOLT:UDEF[:LEV]:A
PP append_list
Adds the current or voltage output data to
the end of the list set by the
[:SOUR[c]]:ARB:<CURR|VOLT>:UDE
F[:LEV] command, to which some data
might be appended to by this command.
Total number of data in the list must be
≤
100000.
append_list: List of the current or voltage
output data. Multiple data can be set to
append_list. Each data must be separated
by a comma.
[:SOUR[c]]:ARB:CURR:UDEF[:LEV]:P
OIN?
[:SOUR[c]]:ARB:VOLT:UDEF[:LEV]:P
OIN?
Returns the number of data in the list set
by the
[:SOUR[c]]:ARB:<CURR|VOLT>:UDE
F[:LEV] command, to which some data
might be appended to by the
[:SOUR[c]]:ARB:<CURR|VOLT>:UDE
F[:LEV]:APP command.
[:SOUR[c]]:ARB:CURR:UDEF:TIME
time
[:SOUR[c]]:ARB:VOLT:UDEF:TIME
time
[:SOUR[c]]:ARB:CURR:UDEF:TIME?
[DEFault|MINimum|MAXimum]
[:SOUR[c]]:ARB:VOLT:UDEF:TIME?
[DEFault|MINimum|MAXimum]
Set the step time of the user defined
waveform.
time=MINimum|MAXimum|DEFault|
1E-5 to 1000 seconds.
1E-5
[:SOUR[c]]:ARB:FUNC[:SHAP] shape
[:SOUR[c]]:ARB:FUNC[:SHAP]?
Selects the shape of the arbitrary
waveform output.
shape=EXPonent|RAMP|SINusoid|
SQUare|TRAPezoid|TRIangle|UDEFined
SQU
Command Summary Reset setting
