2- 54 Keysight B2961A/B2962A SCPI Command Reference, Edition 6
Subsystem Command Summary
Controlling Source/Measure Trigger
:LXI:EVEN[:OUTP]:LAN[:SET]:DRIV
event,drive
:LXI:EVEN[:OUTP]:LAN[:SET]:DRIV?
event
Specifies the trigger drive behavior for
the specified LAN output event.
event: LAN event name
drive=OFF|NORMal|WOR
OFF
:LXI:EVEN[:OUTP]:LAN[:SET]:ENAB
event,status
:LXI:EVEN[:OUTP]:LAN[:SET]:ENAB?
event
Enables or disables the specified LXI
LAN output event.
event: LAN event name
status=0|OFF|1|ON
OFF
:LXI:EVEN[:OUTP]:LAN[:SET]:IDEN
event,id
:LXI:EVEN[:OUTP]:LAN[:SET]:IDEN?
event
Specifies the custom string that will be
transmitted as part of the output event.
event: LAN event name
id: Identifier
event
:LXI:EVEN[:OUTP]:LAN[:SET]:SLOP
event,slope
:LXI:EVEN[:OUTP]:LAN[:SET]:SLOP?
event
Sets the slope of the event transition.
event: LAN event name
slope=POSitive|NEGative
POS
:LXI:EVEN[:OUTP]:LAN[:SET]:SOUR
event,anyEvent
:LXI:EVEN[:OUTP]:LAN[:SET]:SOUR?
event
Designates the instrument that the
specified LAN output event is tied to.
event: LAN event name
anyEvent: One of the following event
names.
WaitingForAcquireArm1,
WaitingForAcquireArm2,
WaitingForAcquireTrigger1,
WaitingForAcquireTrigger2,
WaitingForTransitionArm1,
WaitingForTransitionArm2,
WaitingForTransitionTrigger1,
WaitingForTransitionTrigger2,
Measuring1, Measuring2, Settling1, or
Settling2
""
Command Summary Reset setting
