Introduction 1
Keysight N1911A/1912A User’s Guide 37
Press this key to start and stop the acquisition of the measurement.
Press these keys to enter numeric values in the pop-up fields, for example, the
offset values. To complete the entry use the softkey.
Connector Function
The power reference is a 1 mW (0 dBm) 50 MHz signal available
from a 50 W type-N connector. It is used for calibrating an 8480,
E-Series or N8480 Series power sensor and meter system. If the
meter is configured with Option 003, the connector is fitted to the
rear panel. The Green LED beside the connector is lit when the
calibrator is turned on.
The sensor input connectors (N1912A shown, the N1911A has one
input). If the meter is configured with Option 003, the connectors
are fitted to the rear panel.
