Keysight N9038A Service Guide

Keysight N9038A MXE Service Guide 469
Service and Diagnostics Menus
Service Key Descriptions
Radiated
This will select the radiated filter path. Once selected, one of the
seven different radiated filters paths can be selected from a
submenu, along with the frequency it will be tuned to. This will allow
the viewing of the frequency response of the selected filter.
Tuned Frequency
Since the radiated band filters are all tunable, except Band 6,
once a radiated filter band is selected the frequency to which it
will be tuned to can then be adjusted with this setting. The
minimum and maximum tune frequency for each of the tunable
filter is listed in Table 16-1.
Radiated Band
This will allow access to a menu where the different radiated filter
bands can be selected.
Band 0
Selects the 30 MHz to 70 MHz tunable filter path
Band 1
Selects the 70 MHz to 150 MHz tunable filter path
Band 2
Selects the 150 MHz to 300 MHz tunable filter path
Band 3
Selects the 300 MHz to 600 MHz tunable filter path
Band 4
Selects the 600 MHz to 1 GHz tunable filter path
Band 5
Table 16-1 Tunable Radiated Filter Frequencies
Radiated
Filter Band
Filter
Frequency Range
Allowable Start
Tune Frequency
Allowable Stop
Tune Frequency
Band 0 30 MHz to 70 MHz 27.34 MHz 74.30 MHz
Band 1 70 MHz to 150 MHz 62.50 MHz 156.3 MHz
Band 2 150 MHz to 300 MHz 140.6 MHz 312.5 MHz
Band 3 300 MHz to 600 MHz 281.3 MHz 625.0 MHz
Band 4 600 MHz to 1 GHz 562.5 MHz 1.063 GHz
Band 5 1 GHz to 2 GHz 937.5 MHz 2.125 GHz
