482 Keysight N9038A MXE Service Guide
Replaceable Parts
Replaceable Parts
MP4 Chassis Side, Right (inner) W1312-00116
MP5 Chassis Side, Right (outer) N9020-00014
MP6 Rear Panel (Serial # ≥ MY/SG53220000) N9038-00100
(Serial # < MY/SG53220000) E4449-00100
(Option LSN) N9038-00100
MP7 Chassis, Midplane Bracket W1312-00048
MP8 Chassis, Front Bracket N9038-00003
MP9 Bracket, Power Supply W1312-00131
MP10 Top Brace Assembly N9030-60005
MP11-14 Vibration Mounts 0460-2725
MP15-17 Fan Guard 3160-0281
MP18 Chassis Gusset, Input Connector W1312-00093
MP19 Bracket, Attenuator A (Option 503, 508, and 526) E4449-00103
Bracket, Attenuator A and B (Option 544) N9038-01202
MP20 Bracket, Attenuator B (Option 503, 508, and 526) E4449-00103
MP21 Bracket, RF Switch/High Band Preamp
Assembly
(Option 503, 508, and 526) N9020-00023
(Option 544) N9020-00013
MP22 Bracket, SW1 & SW2
(Option 503, 508, and 526) N9038-01201
(Option 544) N9038-01203
MP23 Dress Cover W1312-00119
MP24 Front Panel Impact Cover W1312-40025
MP25-26 Strap Handle E8251-60067
MP27-30 Instrument Rear Feet 5041-9611
MP31-52 Chassis Board Guide W1312-40001
MP53-54 Retainer, Type-M Cable, Top N9038-40001
MP55-56 Retainer, Type-M Cable, Bottom N9038-40007
MP57 Cable Hold Down 1 (158 mm) 5023-1397
MP58 Cable Hold Down 2 (48 mm) 5023-1379
MP59 Label, Blank, (rear panel) N9020-80057
Table 17-1 All Replaceable Parts
Reference
Designator
Description Part Number
To Next Page
