Keysight N9038A Service Guide

Keysight N9038A MXE Service Guide 483
Replaceable Parts
Replaceable Parts
MP60 Shield, Magnetic - Attenuator A (Option 544) N9020-00043
MP61 Shield, Magnetic - Attenuator B (Option 544) N9020-00044
MP62 Label, EXM warning (Option EXM) N9030-80018
SW1 Cal Switch, SPDT Unterminated Latching,
3-Port
N1810-60077
SW2 Transfer Switch, DC-26.5 GHz, 4-Port (Option 503, 508, and 526) 87222-60026
Transfer Switch, DC-50.0 GHz, 4-Port (Option 544) 87222-60036
W1 Cable, Ribbon, RF Presel Input Assy (A21)
J602 to Limiter Assy (A23) J108 N9038-60009
W2 Cable, Ribbon, RF Presel Input Assy (A21)
P600 to SW1 & SW2 Control N9038-60010
W3 Cable, Ribbon, Front End Control (A15)
J800 to Atten A (A9) & B (A10) E4410-60157
W4 Cable, Ribbon, Front End Control (A15) J700 to
RF Switch/High Band Preamp (A11) J4 E4410-60160
W5 Cable, Ribbon, Front End Control (A15)
J102 to Front End Assy (A13) J12 E4410-60156
W6 Cable, Ribbon, Limiter Assy (A23) P2 to
A1A5J1 & A1A6J1
N9038-60011
W7 Cable, Ribbon, Digital IF (A3) J100 to
Analog IF (A2) J820
E4410-60162
W8 Cable, Ribbon, Front Panel Interface (A1A2)
P1 to Motherboard (A8) J9 N9020-60078
W9 Cable, Ribbon, LISN Control (A30) J1 to
Rear Panel AUX I/O
N9038-60028
W10 Cable, Ribbon, Wideband Analog IF (A25) J2
to Wideband Digital IF (A26) J778
8121-1854
W11 Reserved
W12 Cable, Wire Harness,
Front End Ctrl (A15) J300 to YTF (A12) J1
(Serial # ≥ MY/SG52130014) N9020-60059
(Serial # < MY/SG52130014) E4410-60158
W13 Reserved
Table 17-1 All Replaceable Parts
Reference
Designator
Description Part Number
