Keysight N9038A Service Guide

492 Chapter 17 Replaceable Parts Replaceable Parts
Front Panel Interface Board
(A1A2)
Front Frame (A1A1MP1) 13 0515-1521 Flat Head M3 X 0.5
(5 mm)
Torx T-10 9 inch lbs.
Front Panel Shield
(A1MP19)
Front Frame (A1A1MP1) 4 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Input 2 LED Board (A1A6) Input 2 LED Board
Bracket (A1MP20)
2 0515-0365 Pan Head M2 X 0.4
(4 mm)
Torx T-6 3 inch-lbs
Input 2 LED Board Bracket
(A1MP20)
Front Frame (A1A1MP1) 1 0515-1227 Flat Head M3 X 0.5
(6 mm)
Torx T-10 9 inch-lbs
Input Connector
Assemblies (J1 & J2)
Chassis Base (MP1) 2 per 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Limiter Assembly (A23) Chassis Front Bracket
(MP8)
4 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
SW1 & SW2 Bracket
(MP22)
1 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Midplane Assembly (A7) Midplane Bracket (MP7) 6 0515-0375 Pan Head M3 X 0.5
(16 mm)
Torx T-10 9 inch-lbs
Midplane Bracket (MP7) Chassis Sides, Inner
(MP2 & MP4)
4 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Motherboard (A8) 4 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Motherboard Assembly
(A8)
Chassis Base (MP1) 4 0515-0372 Pan Head M3 X0.5
(8 mm)
Torx T-10 9 inch-lbs
Table 17-3 Attaching Hardware
Attach To Qty Part Number Type Type Tool Torque
