Keysight N9038A Service Guide

Chapter 17 493
Replaceable Parts
Replaceable Parts
Power Supply Bracket
(MP9)
Chassis Sides, Inner
(MP2 & MP4)
4 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Chassis Sides, Outer
(MP3 & MP5)
4 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Power Supply (A6) 3 0515-1227 Flat Head M3 X0.5
(6 mm)
Torx T-10 9 inch-lbs
Rear Feet (MP27-30) Rear Panel (MP6) 4 0515-1619 Pan Head M4 X 0.7
(25 mm)
Torx T-20 21 inch-lbs
4 3050-0893 Lock Washer n/a n/a n/a
Rear Panel (MP6) Misc. Items 16 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Reference Assembly (A16) Chassis Sides, Inner
(MP2 & MP4)
2 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
RF Switch / High Band
Preamp Assembly (A11).
RF Switch / High Band
Preamp Bracket (MP21).
4 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
RF Switch / High Band
Preamp Bracket (MP21)
Chassis Side, Inner (MP4) 2 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Strap Handles (MP25& 26) Chassis Sides, Outer
(MP3 & MP5)
2 per 0515-0710 Flat Head M5 X 0.8
(18 mm)
Torx T-20 21 inch-lbs
SW1 & SW2 Bracket
(MP22)
Chassis Side, Inner (MP4) 2 0515-0372 Pan Head M3 X 0.5
(8 mm)
Torx T-10 9 inch-lbs
Table 17-3 Attaching Hardware
Attach To Qty Part Number Type Type Tool Torque
