628 Keysight N9038A MXE Service Guide
Assembly Replacement Procedures
Front Frame Assembly
Item Description
1 Front Frame
2 Main Keyboard Overlay
3 Overlay, Left Display
4Cover Plate
5 Front Frame Side Trim Strip (plastic)
6 Front Frame Ground Spring
9 A1A2 Front Panel Interface Board
10 A1A2MP1 Speaker
11 A1A2MP2 Speaker Foam
12 A1A3 Liquid Crystal Display (LED backlight)
14 A1A5 Front Panel Daughter Board
15 A1MP1 Main Keypad
16 A1MP2 Display Keypad
17 A1MP9 RPG Knob
18 A1MP3 Nameplate Label, 8.4 GHz or 26.5 GHz
19 A1MP8 LCD Lens Gasket
20
A1MP7 LCD Glass Filter
24 A1A4 Display Backlight Power Supply
26 A1MP19 Shield, Front Panel Interface
30 A1MP14 Display Bracket
33 A1A6 Input 2 LED Board
37 A1MP20 Bracket, Input 2 LED Board
