636 Keysight N9038A MXE Service Guide
Assembly Replacement Procedures
Front Frame Assembly
Item Description
1 Front Frame
2 Front Frame Side Trim Strip (plastic)
3 Front Frame Side Trim Strip (vinyl)
4 Main Keyboard Overlay
5 A1MP9 RPG Knob
6 A1MP3 Nameplate Label
7 Overlay, Left Display
8Cover Plate
9 A1MP7 LCD Glass Filter
10 A1MP8 LCD Lens Gasket
11 A1MP2 Display Keypad
12 Front Frame Ground Spring
13 A1MP1 Main Keypad
14 A1A2MP2 Speaker Foam
15 A1A2MP1 Speaker
16 A1A2 Front Panel Interface Board
17 A1A5 Front Panel Daughter Board
18 A1W1 Flex Circuit, Front Panel Interface to LCD
19 A1A3 Liquid Crystal Display
20 A1MP14 Display Bracket
21 A1MP10-13 Cable Clamp
22 A1MP19 Shield, Front Panel Interface
24 A1W2 Cable Assembly, Wire Harness, Front Panel Interface to
Backlight Power Supply
25 A1MP17 Shield, Inverter Assembly, Bottom
26 A1A4 Display Backlight Power Supply
27 A1MP15 Shield, Inverter Board
28 A1MP16 Shield, Inverter Assembly, Top
33 A1A6 Input 2 LED Board
34 A1MP20 Input 2 LED Board Bracket
