Koden MDP-621 - Model Outline; Radar Plotter

Chapter1 MDP-621/641/640
General Information Operation manual
1.3.1 Model outline
1.3.1.1 Radar Plotter
GPS-20A(B-Type)
GPS Sensor
(Option)
Transceiver RB716A
4kW Open
Aerial
3 ft (RW701A-03) /
4 ft (RW701A-04)
NME
A
-0183 I/O
O
p
tion
To Network
Option
Transceiver
RB714A
2kW Radome
1.2 ft
Transceiver
RB715A
4kW Radome
2 ft
GPS Compass
(Option)
KGC-1
7 inch Display
RGD-600
Figure 1. 1 Outline of Radar Plotter models
1-2 0093161022-06
