10.4.5 SCAN Speed
Sets the rotation speed of the antenna.
When using the RB714A 2kW Antenna (MDP-621), the rotation speed cannot be set.
Set the rotation speed in the standby mode (Cannot be set while transmitting).

0
1
2
Display
ATA Preset
3
4
Range Setup1
Range Setup2
5
6
SCAN Speed
Adjust
RADAR





0
STD
HIGH
1
SCAN Speed





 STD: Standard rotation (24rpm).
 HIGH: High speed rotation (48rpm).

10.4.6 Adjust

0
1
2
Display
ATA Preset
3
4
Range Setup1
Range Setup2
5
6
SCAN Speed
Adjust
RADAR

0
1
2
TX Timing Adjust
Heading Adjust
Tuning Adjust
3
4
Antenna
GAIN
STC
5
Adjust








The items in the Adjust menu should be done immediately after the installation. These items need not
be changed during normal operation.
