Navigation Data operation
Chapter 9 Navigation Data Operation
9.1 Navigation Data display
Navigation data such as own ship’s position, waypoint data etc. is displayed at the top of the screen
The type of navigational data displayed is changed by the soft keys.
Furthermore, the alarm functions associated with navigation (Arrival, anchor watch, course deviation,
speed and water temperature alarm) are set via the soft keys of the Navigation Data (NAV). 
Navigation Data display
