Koden MDP-621 - Connector Pinouts

MDP-621/641/640 Chapter 4
Operation manual Installation
4.7 Connector pinouts


POWER

NMEA in/out
J2

J5
GPS sensor
J3
Ext buzzer output
J7
Radar antenna
LAN in/out

J1
1:ＤＣ−
2:ＤＣ＋
3:NC
4:NC
5:GND
1: GND
2: TX
3: GND
4: RX+
5: RX-
6: NC
1: GND
2: GPSOUT
3: GND
4: GPSIN+
5: GPSIN-
6:＋12V
1:RXD
2:TXD
3: BUZ1
4: BUZ2
5: +12V
6: GND
7: +5V
8: GND
1: LPTX+
2: LPTX-
3: LPRX+
4: LPRX-
5: GND)
1: +250V
2: +24V
3: +12V
4: GND
5:DAT-R
6:DAT
7:NC
8:BP/SHF
9:BP/SHF-R
10:V/TRIG
11:NC
12: MOTOR+
13: MOTOR+
14:V/TRIG-R
15: MOTOR-
16: MOTOR-
1
5
2
3
4
1 5
6
2
3
4
1
5
6 2
3
4
8
16 15
13 12 11
9 8 7
234
6
1
5
10
14
7
1
5
2
3
4



























1 5
6
2
3
4







0093161022-06 4-19
