Chapter 10MDP-621/641/640
MENU operation Operation manual
10.4.1 Display
Sets up the parameters associated with the Radar screen display.

0
1
2
Display
ATA Preset
3
4
Range Setup1
Range Setup2
5
6
SCAN Speed
Adjust
RADAR
0
1
2
Cursor Position
EBL Bearing
HL Flash
3
4
Stern Mark
North Mark
5
WPT Mark
6
Parallel Cursor
+MK Line
7
Display









(1) Cursor Position
Selects the type of cross cursor position data to display.
Setting range: Position, DIST/BRG(REL), DIST/BRG(TRUE)
Initial setting: DIST/BRG(REL)

0
Position
1
DIST / BRG(REL)
2
DIST / BRG(TRUE)
Cursor Position





(2) EBL Bearing
Selects the True or Relative bearing cursor.
Setting range:  REL, TRUE
Initial setting:  REL

0
REL
1
TRUE
EBL Bearing




(3) HL Flash
Turns the function that highlights the heading line on every rotation of the antenna ON or OFF.
Initial setting: OFF
0
OFF
1
ON
HL Flash




