Chapter1 MDP-621/641/640
General Information Operation manual
1.3.2.2 Radar Plotter multi-display
GPS-20A(B-Type)
GPS Sensor
(Option)
Transceiver
Open
Transceiver
Radome
GPS Compass
(Option)
KGC-1
NME
A
-0183 I/O
Option
O
p
tion
1st Display
RGD-600
Or
RGD-120
2nd Display
RGD-600
Or
RGD-120
Figure 1. 3 Network outline of Radar Plotter multi-display
1-4 0093161022-06
