(1) Select the drawing color with the COLOR key.
(2) Position the cross cursor at the origin of the drawing.
(3) Press the “ENTER” key.
(4) Position the cross cursor at the next point of the drawing and press the ”ENTER”key.
Repeat step 4.
 Use the COLOR settings menu to change the color while drawing.
(5)Press the “END” key to terminate without joining to the start point.
Press the “CLOSE END” key to join the points and then to terminate.
6.4.10.2 Erasing a drawing
There are 2 methods available to erase a drawing. One method is to erase a selected drawing color,
the other is to erase an assigned area.

(1) Drawing color select and erase method
When the cross cursor is displayed press the “CURS” key to turn the cross cursor off.
Press the “DRAW ERASE” key to display the drawing erase menu.
PLOTTER/PAGE1(2)/P FUNC/DRAW ERASE
PLOTTER
PAGE1
COLOR
AREA
START
RETURN
ARE
A
END
ERASE
PLOTTER
PAGE1
YES
NO

COLOR
DBL
Y
EL
RED
4
5
BLU
PNK
6 WHT
7 ALL
3
2
1
0
GRN
(a) Select the color of the drawing to be erased with the COLOR
key.
(b) Press the “ERASE” key.
(c) The soft menu and message shown below are displayed.
(d) If the “YES” key is pressed, the drawing lines of the selected
color will be erased. (Pressing “NO” causes the system to
return to the top menu without erasing the drawing.)
A
SSIGNED DRAWING LINE WILL BE
ERASED. ARE YOU SURE?


The “COLOR” key displays the color settings menu fo
r
the drawing to be erased. Use the pointing keypad o
r
the rotary control to set the color.
The color that has been set is displayed in the bottom
part of the soft menu.
The color settings menu can be closed by pressing the
“MENU” key.
