MDP-621/641/640 Chapter 10
Operation manual MENU operation
10.4.3 ATA Preset
Sets up the parameters for the ATA operation.

0
1
2
Display
ATA Preset
3
4
Range Setup1
Range Setup2
5
6
SCAN Speed
Adjust
RADAR
0
1
2
CPA Set
TCPA Set
VECT Set
3
VECT Mode
ATA
4
ATA Preset








(1) Closest point of approach distance (CPA Set)
Sets up the desired distance for the closest point of approach.


nm
0.0
CPA Set




(2) Time to reach closest point of approach (TCPA Set)
Sets up the time taken to reach the closest point of approach.


min
0
TCPA Set



(3) Vector time (VECT Set)
Sets up the vector time (Speed x Time = vector length).

min
0
VECT Set



(4) Vector mode (VECT Mode)
Selects the vector data display mode. “TRUE” for true bearing and speed. “REL” for relative
bearing and speed.

0
REL
1
TRUE
VECT Mode



