MDP-621/641/640 Chapter 3
Operation manual Specifcications
3.7 External dimensions and weight
3.7.1 Display
Dimensions: 247 (H) x 220 (W) x 133.5 (D), unit in mm
Weight: 3.5 kg
247
220
133.5220
3.7.2 Radar antenna
3.7.2.1 RB714A
Dimensions: 220 (H) x 448 (W) x 448 (D), unit min
Weight: 6 Kg
Bow
448
448
220
0093161022-07 3-7
