MDP-1241/1240/1260/1210 Chapter 8
Operation manual Sounder operation
(3) Adjusting the high frequency sensitivity
If the “H GAIN” key is pressed, the GAIN adjustment box shown below is displayed.The method of
operation is the same as the L GAINmethod.

50 H GAIN




(4) Adjusting the high frequency enhance
If the “H ENH” key is pressed, the ENHANCE adjustment box shown below is displayed.The
method of operation is the same as the L GAINmethod.

50 H ENH




8.3.2.2. Auto adjustment
Generally with the auto-adjust function, operation is not necessary, but fine adjustment can be carried
out to ensure the desired image is properly displayed.

(1) Fine adjustment of the low frequency sensitivity
If the “L ADJ” key is pressed, the sensitivity fine adjustment box shown below is displayed.
The method of operation is the same as the L GAINmethod.

50 L ADJ




(2) Fine adjustment of the high frequency sensitivity
If the “H ADJ” key is pressed, the sensitivity fine adjustment box shown below is displayed.
The method of operation is the same as the L GAINmethod.

H ADJ 50



0093161202-06 8-7
