Chapter 10MDP-621/641/640
MENU operation Operation manual
10.3 Plotter MENU
The functions listed below are set with the PLOTTER MENU.

0 Display 0 Track Line (Thin Line, Thick line)
 1 Course Line (OFF, Long Length Line, Speed response)
2 Own Ship’s Mark (Small Circle, Large Circle , Dot ,
Shop’s Profile(S) , Ship’s Profile(L))
3 Rings (OFF, ON)
4 Mark Size (Small, Large)
5 Text Size (Small, Large)
6 Object Icon (Multiple, Simple)
 7 Chart Display 1 0 Chart Border Line (OFF, PLOTTER,
PLOTTER / OVERLAY)
1 L / L ( // )
2 Place Name ( // )
3 Lake / River ( // )
4 Structure ( // )
5 Landmark ( // )
6 Port(s) ( // )
7 Mixing Levels ( // )
8 Chart Display 2 0 Hazardous Area ( // )
1 Lighthouse ( // )
2 Buoy ( // )
3 Signal ( // )
4 Traffic Routes ( // )
5 Tide and Current ( // )
6 Depth ( // )
7 Seabed ( // )
8 Depth Contour ( // )
9 Under Water Object ( // )
9 Chart Display 3 0 Roads ( // )
1 Road Name ( // )
2 POI ( // )
10-20 0093161022-06
