MDP-621/641/640 Chapter 10
Operation manual MENU operation
10.5 Sounder MENU
The functions listed below are set up with the SOUNDER MENU.
0 Display 0 Depth Display (OFF, Small, Middle, Large)
1 Depth Position (Bottom, Top)
2 Scale Display (OFF, Single, All)
3 Scale Position (Side, Center)
4 Scale Value (Small, Large)
5 Time Mark (OFF, 10 SEC, 1 MIN)
6 Image Direction (←｜← , ←｜→)
7 Image Split (Length, Width)
8 Image Swap (A|B, B|A)
9 Color Bar Scale (OFF, ON)
1 Image 0 Enhance 25,35,45,55,65
1 White Line (OFF, 1, 2, 3, 4, 5)
2 Mix (A, B, C)
3 Smoothing (OFF, ON)
4 Water Temp Graph (OFF, ON)
2 Transmission 0 Pulse (High) (1, 2, 3, 4)
1 Pulse (Low) (1, 2, 3, 4)
2 Output (Normal, Low)
3 Depth Range Preset 0 Range 1
1 Range 2
2 Range 3
3 Range 4
4 Range 5
5 Range 6
6 Range 7
7 Range 8
4 Adjust 0 Draft Set
1 Bottom Det Start
2 Bottom Det Lvl(H)
3 Bottom Det Lvl(L)
4 Bottom Det Range (Within display, Outside display)
5 Depth (Auto, High, Low)
6 Sonic correction
0093161022-06 10-55
