MDP-621/641/640 Chapter 7

Operation manual Radar operation

93161022-03 7-21

7.4.19 Setting up the tuning (TUNE)

Changes the tuning function between automatic and manual and performs manual tuning adjustment.



Display the soft menu (RADAR/PAGE1(2)/R FUNC/TUNE) to carry out tuning.

(1) Changing between Auto/Manual tuning



(2) Manually adjusting the tuning

Switch the auto/man tuning to manual. If the “TUNE” key is pressed, the adjustment box shown

below is displayed.

Using the rotary control adjust the TUNE.

RADAR/PAGE1(2)/R FUNC/TUNE

MANUAL

RETURN

AUTO

RADAR

PAGE1

TUNE

If the key is pressed when “AUTO” is

displayed the tuning will be changed

to ”MANUAL”.

If the key is pressed when “MANUAL” is

displayed the tuning will be changed

to ”AUTO”.

This key changes between AT⇔

XX in conjunction with AUTO⇔
