MDP-1241/1240/1260/1210 Chapter 8
Operation manual Sounder operation
8.3.11 Color clearing operation
When the ship is underway, thin blue and white noise lines resulting from sea turbulence, background
ocean noise, etc., may appear on the screen. Additionally, some fish species are always displayed in a
certain color. In these situations, fish schools can be made more easily recognizable by limiting the
number of display colors.
Display the soft menu (SOUNDER/PAGE1(2)/S FUNC/COLOR).
If the“COLOR REJ”key is pressed, the adjustment box is displayed.
Use the joystick to select the color for clearing.


COLOR REJ



BKGND
COLOR
SOUNDER/PAGE1(2)/S FUNC/COLOR
TONE
1
COLOR
REJ
RETURN
SOUNDER
PAGE1

0093161202-06 8-17
