MDP-621/641/640 Chapter 5
Operation manual Basic operation
0093161022-06 5-11
(8)Press soft key “6” ( ENTER ).
The newly created screen is registered and the system returns to the display mode screen.
(9) Using the rotary control, position the cursor over the icon of the screen to be displayed and press soft
key “6” ( ENTER ).
(Note)
If the operation stops when changing the registration screen press the ”DISP” key.
-The display screen returns to the previous screen.
-The screen that was being changed during the operation is not registered and the system
returns to the previous registration screen.
DISP
FULL
ENTER
1/2
RADAR
PLOT
SNDR
OVRLY
NAV
NAV
3D
OV/3D
PL/SD
HIWAY
CMPAS
screen
CREATE
The icon is now displayed
with Plotter in top, Radar in
bottom.
(6)
Select the
Radar icon.
To Next Page
