Operation
215
Pos: 34.45 /BA/Bedienung / Großpackenpresse/ Antriebe/Raffer trommelantrieb @ 20\mod_1 238992855613_78.d oc @ 225381
11.13 Packer drum drive
The drive of the feed packer drum is located on the left side of the machine. The gearbox is
protected by a spring-loaded ratchet clutch.
Fig. 145
BP 890 / BP 1270 BP 1290 BP 12130
Note
As soon as the ratchet clutch responds, stop the tractor and reduce the speed until the machine
has cleared itself again. After the fault is rectified, the ratchet clutch automatically resumes its
work.
An error message appears on the display of the control unit.
