Introduction
26
Pos: 10.49 /Überschri ften/Überschri ften 3/F-J/Hydrauli kanschlüsse @ 17\mod_123618 0925308_78.doc @ 202059
3.9.1 Hydraulic connections
Pos: 10.50 /BA/Inbetr iebnahme/Schwader /Hinweis Hydraulikauf kleber beachten @ 9\mod_12 19997531785_78.doc @ 124879
Note
Connect the hydraulic lines correctly
• The hydraulic hoses are identified by coloured hose clips.
• When connecting the hydraulic lines, observe the sticker for the tractor hydraulics (see
the "Safety" chapter: "Position of the general information labels on the machine").
Pos: 10.51 /BA/Einlei tung/Maschinenüber sicht/Großpackenpr essen/Hydraulik anschluss Pick up/Len kachse/Stützfuß @ 17\ mod_1236181032027_78. doc @ 202080
Depending on the design of your BiG PACK baler, the following connections are possible:
• Pick-up lifting mechanism (1) single-acting control valve (red 2)
• Locking the steering axle (5) single-acting control valve (red 7)
• Parking jack (hydraulic) (no Fig.) double-acting control valve
• Parking jack up (red 6)
• Parking jack down (blue 6)
Pos: 10.52 /BA/Einlei tung/Maschinenüber sicht/Großpackenpr essen/Hydraulik anschlüsse Ausführun g Komfort - Elektroni k: (2011-03-03 12:12: 36) @ 17\mod_123618135984 0_78.doc @ 202128
Comfort version electronics:
• Valve block pressure (9) single-acting control valve (NW 15) (red 1)
• Valve block return (3) return tank (NW 18) (blue 1)
• LS message line (4) LS connection (NW 12) (red 3) (only on tractors with load sensing
hydraulics)
