13.14 Examples of Emergency Manual Activation
Pos: 42.37.14 /BA/Si cherheit/Gefahrenhin weise/Ladewagen/ Gefahr Not-Hand-Be tätigung @ 0\mod_11999454 55397_78.doc @ 36965
Danger! - Unexpected actions on the machine.
Effect: Danger to life or serious injuries.
• Only persons who are confident with the machine may perform emergency manual
activation.
• The person performing the activation must know which machine parts are affected by
controlling the valves.
• The manipulation of the valves must only be carried out from a safe position outside the
range of the machine parts which are moved by the actuators.
• Ensure that no persons, animals or objects are within this danger zone.
Pos: 42.37.15 /BA/W artung/Load-Sensing/ Großpackenpresse/ Not-Hand-Betätigu ng Beispiele @ 24\mod_12415 17072555_78.doc @ 2457 13
Activate relevant valves in order to accomplish a function (e.g. lift/lower roller chute). The
respective diagrams (hydraulic bloc comfort) show which valves must be switched.
Hereinafter an example is described according to the comfort version.
13.14.1 Lifting/lowering the roller chute
• Turn in both knurled head screws on the valve (A1 and B1) “Roller chute”
To lift:
• Using a pointed object, press in the magnetic plunger of valve (A) "Control valve" and
hold it pressed in
To lower:
• Using a pointed object, press in the magnetic plunger of valve (B) "Control valve" and
hold it pressed in
Note
After emergency manual activation has been performed, the knurled head screw for emergency
manual activation must all be completely screwed out again!
