Control Unit – Auxiliary Control
103
Pos: 20.7 /BA/In fo-Center/Sch wader/Bedieneinh eit- Komfort/SW 2 000/Zusatzb edienung/Übersic ht Beschreibu ng der Tasten u ndK ontrollleucht en SW 2000 @ 61\mod_12989 61157233_78. doc@ 568581 @ @ 1
Keys Pilot lamps
Reduce front working width 2 Reduce the working width
Increase front working width 3 Increase the working width
Raise/lower front left rotor 4 Front left rotor
Raise/lower front right rotor 5 Front right rotor
Raise/lower middle left rotor 6 Middle left rotor
Raise/lower middle right rotor 7 Middle right rotor
Raise/lower rear left rotor 8 Rear left rotor
Raise/lower rear right rotor 9 Rear right rotor
Raise/lower rotors in pairs
(front / middle / rear)
10 Rotors in pairs
Lift all rotors 11 Lift all rotors
Lower all rotors 12 Lower all rotors
