Operation
195
Pos: 30.10 /BA/Be dienung /Sch wader/Einstellen der Arbeitstiefe - M edium/Ko mfort SW 1400 @ 4\mod_121206 7918483_78.doc @ 85146 @ 2 @ 1
12.4 Adjusting the raking height
The raking height of the rotors is adjusted by electric motors above the rotors.
The tine tips should lightly touch the ground. If the tine tips require correction during use,
preferably do this while they are moving.
Note
The raking height should be adjusted during use.
Note the following rule:
If the setting is too high, the forage will not be completely collected. If the setting is too low,
there is a risk of soiling the forage, damaging the sward and causing considerable wear to the
double coil spring tines.
• The working depth is adjusted via the control unit (see chapter entitled Comfort / Medium
Control Unit "Adjusting the Working Height of the Rotors").
