Basic screen 2 "Working width/swath width/parallel offset"
STOP
5 6
7
8
B C D
SW2000051
M M
M
Fig. 50
Pos: 16.24.29.2 / BA/Info-Center/Sc hwader/Be dieneinheit - Ko mfort/Gefahr Sch nellstop durch EIN /AUS Taste @ 36\mod_1263 276960200_7 8.doc @ 338506 @ @ 1
DANGER! – Before swivelling the machine, ensure that nobody is within the swivel
range.
Effect: Danger to life or serious injuries.
• Instruct persons to leave the danger zone.
• If required, switch off the machine immediately.
• If there is an imminent danger, press the key (ON/OFF) on the control unit to stop
all functions which are currently being performed.
Pos: 16.24.29.2 / BA/Info-Center/Sc hwader/Be dieneinheit - Ko mfort/SW 2000/Gr undbild 2 Schwa dbreite/Schwa dbreite einstelle n SW 2000 @ 2 3\mod_124 0233496599_78.d oc @ 236778 @3 @ 1
6.13.3 Adjusting the Swath Width
To increase the swath width:
Press the key
To reduce the swath width:
Press the key
