KRONE ISOBUS-Terminal CCI 100
165
Pos: 22.5.76 /B A/Info-Center/CC-I SOBUS-Termi nal/CCI-Ladew agen/Hauptme nüs/Hauptmenü 9I SO-Einstell ungen/Menü 9-1 Softkeys ISO-Ter minal wenig er1 0T asten @ 83\ mod_131711 6511667_78.doc @ 727008 @ 3@ 1
8.14.1 Menu 9-1 "Softkeys ISO terminal"
Note
The menu 9-1 only appears on ISO terminals with less than 10 keys
In menu 9-1, the basic screen (for ISO terminals with less than 10 keys) is set to 5 or 10 softkey
buttons. During the change-over to 10 softkey buttons, additional softkeys will be virtually
included and can be reached by scrolling.
Note
For ISO terminals with less than 10 keys, an additional ISO joystick is recommended for the
convenient operation of the attached machines. For the assignment of the joystick, please refer
to Section "Example of a joystick assignment".
Pos: 22.5.77 /B A/Info-Center/CC-I SOBUS-Termi nal/CCI-Ladew agen/Hauptme nüs/Hauptmenü 9I SO-Einstell ungen/Menü 9-1 i mI SO-Terminal aufrufen 10Tast en@ 83\mod_ 1317116618767 _78.doc @ 727 036 @ @ 1
ZX400107
Fig. 117
Main menu 9 "ISO Settings" appears.
• Press the key to open menu 9-1 ( )
The display shows menu 9-1 "Softkeys ISO terminal".
The current status is displayed as a symbol:
Change the basic screen to 5 softkey buttons
Change the basic screen to 10 softkey buttons
The icon in the upper line indicates that the displayed status is saved.
Change and save status
• Set the desired status with the or key. The icon in the top line goes out.
• Press the key. The set status is saved and the icon appears in the upper line.
• You can use the key to close the menu currently displayed.
• Pressing the key for a little longer calls up the basic screen
