6.5.2 Displays in the main window (II)
STOP
2.5
12.5
h
ha
2
2
5 6
7 8
B C D
SW2000030_1
M M
M
2,2 2,2
2,2 2,2
2,2 2,2
1,8m
15,1m
Fig. 21
1) = Working width
2) = Swath width
h
2 = Operating hours counter, current customer counter
ha
2 = Surface counter
Possible status messages:
2,2
= Rotor in float setting; rotor height indicated in cm
= Rotor (not activated) stopped, not in float setting
0,0
= Lift rotor
0,0
= Lower rotor (to headland position)
= Time delay between lifting/lowering of rotors front to middle
= Time delay between lifting/lowering of rotors middle to rear
