Introduction
15
Pos: 9.20 /BA/Einl eitung/Technis cheD aten @ 0\ mod_119556 6374865_78.doc @ 594 @ 2 @ 1
3.8 Technical data
All information, illustrations and technical data in these operating instructions correspond to the
latest state at the time of publication. We reserve the right to make design changes at any time
and without notification of reasons.
Pos: 9.21 /BA/Einl eitung/Technis cheD aten/Sch wader/Swadro 2 000 @ 61\mod _1298885624 861_78.doc @ 5 67686 @ @ 1
Type Swadro 2000
Understeering coupling Unit standard
Number of rotors Unit 6
Number of arms/rotors (front, middle, rear) Unit 13/13/15
Number of double tines/arm approx. mm 4/4/5
Working width approx. m 10.00 – 19.00
Rotor diameter approx. mm 3300/3300/3380
Height with tine arms/transport position approx. mm 3995
Height in working position approx. mm 2300
Length approx. mm 13150
Width in transport position approx. mm 2995
Width in working position approx. m 10.00 – 19.00
Power consumption approx. kW/HP 90/130
PTO speed rpm max. 540
Equivalent continuous sound pressure level less than 70 d B(A)
Acreage (approx. ha/h) 19
Tyres Running gear 800/45 R 26.5
Running wheels under the rotors 16x6.50-8PR
Tyre pressure Running gear 3.0 bar
Running wheels under the rotors 1.8 bar
Voltage 12 volt, 7-pin DIN plug
12 Volt, — 3-pin plug
Max. operating pressure of hydraulic system 200 bar
Required hydraulic connections 1x SA
1)
+ Free backflow required
1x DA
2)
Service weight kg 9600
Permissible axle load kg 7000
Permissible supporting load kg 2600
Maximum permissible speed km/h 40
3)
1)
SA= Single-action control unit
2)
DA= Double-action control unit
3)
The maximum permissible driving speed varies from country to country. The maximum
permissible driving speed is determined by the relevant national regulations!
