15.2 Adjusting the hydraulic system
Pos: 40.33.5.6 /BA /Wartung/Load-S ensing/SW 1400/Anpassen d esH ydrauli ksystems SW 1400/ 2000 @ 6\mod _1214814979 652_78.doc @ 9 5481 @ @ 1
The Comfort hydraulic system of the machine must be adjusted to the tractor It is designed for
continuous circulation. The adjustment is made by adjusting the hydraulic system screw (1) on
the electromagnetic valve block. The block is located at the front left on the frame of the
machine under the guard.
Note
The adjustment depends on the hydraulic system of the tractor and must be made while there
is no pressure in the machine!
Unscrew the system screw (1) as far as it will go for:
• Tractor with an open (constant-current) hydraulic system (for additional information,
please refer to the tractor manufacturer's operating instructions)
• Tractors with LS pump and non-activated load-sensing system
Note
This adjustment is set when the unit leaves the factory.
Loosen counter nut (2) to make the adjustment, then retighten.
Screw the system screw (1) as far as it will go for:
• Tractors with closed (constant pressure or load sensing) Hydraulic system (For more
information, please refer to the tractor manufacturer's operating instructions)
• Tractors with LS pump and sensing line that is connected
Note
Loosen counter nut (2) to make the adjustment, then retighten.
Pos: 40.33.5.7 /Ü berschriften/Üb erschriften 2/ K-O/Not-Handbetätig ung @ 38\m od_126744025 1396_78.doc @ 355374 @ 2 @ 1
15.3 Emergency manual activation
Pos: 40.33.5.8 /BA /Wartung/Load-S ensing/SW 2000/Not-Han dbetätigung Swa dro 2000 @ 38\mo d_126744063 2786_78.doc @ 355399 @ @ 1
The electromagnetic valve block (I) is located at the front left on the main frame of the machine
under the guard.
The electromagnetic valve block (II) is located at the rear left above the running gear on the
frame of the machine under the guard.
In the event the electrical system should fail completely, the valves are equipped with an
<<Emergency manual activation>>.
• All valves (except Y1 and Y24) are activated by turning in the set-screw
• The valves (Y1 and Y24) can be activated with a pointed object by turning the valve in
