6.5.3 Softkeys area (III)
STOP
2.5
12.5
h
ha
2,2 2,2
2,2 2,2
2,2
2
2
5 6
7
8
B C D
SW2000031
M M
M
2,2
1,8m
15,1m
Figure. 22
M
Pressing the key under the softkey brings up the basic screen "Lifting
the rotors".
M
Pressing the key
B
under the softkey brings up the basic screen "Width
adjustments".
Pressing the key
C
under the softkey brings up the basic screen
"Working height".
is indicated on the lower line of the display if a function from the area (IV)
is activated.
