Maintenance – lubrication chart
227
Pos: 40.35.1 /Üb erschriften/Üb erschriften 1/U-Z/ Wartung - Sc hmierplan @ 0\mo d_119735930 4198_78.doc @ 18232 @ 1 @ 1
16 Maintenance – lubrication chart
Pos: 40.35.2 /B A/Wartung/Achtu ng Das Absch mieren der Masc hine nur in Arb eitsposition durc hführen @ 61\m od_12983864 52868_78.doc @ 565903 @ @ 1
CAUTION!
Only lubricate the machine when it is in the working position.
Pos: 40.35.3 /Üb erschriften/Üb erschriften 2/P-T/S pezielle Sich erheitshinweis e@ 0\mod_1196 660495760_78. doc @ 9134 @ 2@ 1
16.1 Special Safety Instructions
Pos: 40.35.4 /B A/Sicherheit/Gefa hrenhinweise/L adewagen/Ge fahr Wartung allge mein @ 0\mo d_119988406 9862_78.doc @ 36704 @ @ 1
Danger! - When performing repair, maintenance or cleaning work on the machine, or in
the case of technical intervention, drive elements may start moving.
Effect: Danger to life, injuries or damage to the machine.
• Switch off the tractor engine and remove the ignition key
• Secure the machine and tractor against the possibility of rolling back.
• Switch off the PTO and disengage it
• After the repair, maintenance and cleaning work or technical interventions are completed,
mount all protective coverings and safety devices properly again.
• Avoid skin contact with oils, greases, cleaning agents and solvents.
• In the event of injuries or burns due to oils, cleaning agents or solvents, contact a
physician immediately.
• All other safety instructions must also be followed to avoid injuries and accidents.
Pos: 40.35.5 /Üb erschriften/Üb erschriften 2/F-J/G elenkwelle @ 0\mod_1199781 879794_78.doc @ 34542 @ 2@ 1
16.2 PTO shaft
Pos: 40.35.6 /B A/Wartung/Sch wader/Schmierpl an/Abschmier enG elenkwelle Sc hwader @ 2\m od_120279843 7998_78.doc @ 61395 @ @ 1
Figure 161
Lubricate the PTO shafts at the intervals indicated in the drawing with a multi-purpose grease.
Follow the operating instructions of the PTO shaft manufacturer.
