Maintenance - hydraulic system
221
Pos: 40.33.5.18 / BA/Wartung/Loa d-Sensing/SW 2 000/Ventilb eschreibung SW 2 000 @ 39\ mod_126744735753 6_78.doc @ 3 55445 @ @ 1
Valve description
No. Description No. Description
Y 1 Control valve (function 1) Y14 Middle left rotor arm
Y2 / Y3 Steering Y16 Rear left rotor arm
Y4 / Y8 Left supporting wheel Y18 Front right rotor arm
Y 5 / Y9 Right supporting wheel Y20 Middle right rotor arm
Y 6 / Y10 Front working width Y22 Rear right rotor arm
Y 7 / Y11 Rear swath width Y24 Control valve (function 2)
Y12 Front left rotor arm Y25 / Y26 Parallel offset
Pos: 40.33.5.19 / BA/Wartung/Loa d-Sensing/SW 2 000/Hinweis N ot-Handbetätigu ng ist gedacht di e Maschine vomF eld zufahr en @ 39\mod_12 67453493302 _78.doc @ 35 5470 @ @ 1
Note
The emergency manual operation is only intended for transporting the machine from the field to
the nearest workshop.
Pos: 40.33.5.20 / BA/Wartung/Loa d-Sensing/SW 2 000/Bevor Si e dieN ot-Hand betätigung ausf ühren.... @ 39\m od_1267453683 411_78.doc @ 355494 @ @ 1
Before executing the emergency manual operation, move the machine about two metres
forwards to straighten the supporting wheels.
Pos: 40.33.5.21 / BA/Wartung/Loa d-Sensing/SW 2 000/Parallelversc hiebung @ 61\mod_1298 465750424_78.doc @ 566849 @ 3 @ 1
15.4.1 Parallel offset
The cylinders for the parallel offset must be retracted.
If this is not the case, carefully follow the procedure described below!
• Switch off the engine
• Secure the tractor and machine against rolling away.
• Screw set-screws (Y25 and Y26) all the way in
• Start the engine and pressurise the hydraulic system.
• Using a pointed object, press in the magnetic plunger of control valve (Y 1) and hold it
pressed in until the cylinders for the parallel offset are fully retracted
• Switch off the engine
• Screw the set-screws (Y25 and Y26) all the way out
Pos: 40.33.5.22 / BA/Wartung/Loa d-Sensing/SW 2 000/Umstelle n aller Kreiselar me von Arbeitsst ellung/Transports tellung @ 61\mod_12984658 75610_78.doc @ 566876 @ 3 @1
15.4.2 Moving all rotor arms from working position to transport position
The following instructions must be strictly observed!
• Switch off the engine
• Secure the tractor and machine against rolling away.
• Screw in the set-screws (Y18, Y20, Y22 right side of the machine) and
(Y 12, Y14, Y16 left side of the machine)
Note
The valves (Y18, Y20, Y22, Y 12, Y14, Y16 ) are for the supply line (no adjustable throttles are
fitted in the supply line)
• Start the engine and pressurise the hydraulic system.
• Using a pointed object, press in the magnetic plunger of control valve (Y 1) and hold it
pressed in until the rotor arms are raised into the transport position
• Switch off the engine
• Screw out the set-screws (Y18, Y20, Y22 right side of the machine) and
(Y 12, Y14, Y16 left side of the machine)
