KRONE ISOBUS-Terminal CCI 100
139
Pos: 22.5.12 /B A/Info-Center/CC-I SOBUS-Termi nal/CCI-Swa dro/Swadro 2000/Ha uptmenüs/H auptmenü 1 Ei nstellungen/M enü 1-3Ü berlappu ng @ 89\mod _1322556720822 _78.doc @ 76 3612 @ 3 @ 1
8.8.2 Menu 1-3 "Overlap"
1-4
CCS00083
CCS00084
1- 4
A
Fig. 98
In this menu, the overlap can be used to set the accuracy of the counter for total surface.
Calling the menu
Main menu 1 "Settings" appears.
Press the function key or to enter menu 1-4 . The background of the
selected symbol turns grey.
Press function key
The display shows menu 1-3 "Overlap".
The bar display and value (A) indicate the preselected overlap.
The icon in the upper line indicates that the displayed value has been saved.
Use function key or to set the overlap. The icon in the upper line disappears
Press function key . The set value is saved and the symbol appears in the
upper line.
Pressing the function key displays the value of the factory setting (Press the
function key , the value of the factory setting is saved, the symbol appears in
the upper line)
Press function key to close the currently displayed menu
Pressing the key for a little longer calls up the basic screen
