Maintenance
209
Pos: 40.17.6 /B A/Wartung/Reife n/Schwader/Reif en-Luftdruck T abelle Schwad er2 000 @ 22\m od_12397865 75316_78.doc @ 2 33441 @ @ 1
Tyre identification Tyre pressure [bar]
16x6.50-8 4PR 1,8
500/50-17 10 PR 3,0
560/45 22.5 (optional) 3,0
Pos: 40.17.7 /B A/Wartung/Reife n/Anziehdrehm oment @ 0\mo d_11999559054 60_78.doc @ 37 340 @ @ 1
Tightening Torque
Threading Key size in
mm
Number of bolts
per hub -
pieces
Max. tightening torque
black galvan.
M12 x 1.5 19 4/5 95 Nm 95 Nm
M14 x 1.5 22 5 125 Nm 125 Nm
M18 x 1.5 24 6 290 Nm 320 Nm
M20 x 1.5 27 8 380 Nm 420 Nm
M20 x 1,5 30 8 380 Nm 420 Nm
M22 x 1.5 32 8/10 510 Nm 560 Nm
M22 x 2 32 10 460 Nm 505 Nm
