Maintenance
213
SW2000017
Fig. 153
Pos. Sensor Designation Tightening torque
1 Pivoting arm in transport position 10 Nm
2 Self steer 10 Nm
3 Supporting wheel swung forward 10 Nm
4 Working height for all rotors 10 Nm
5 Working width 10 Nm
6 Swath width 10 Nm
7 Transport position for travelling carriages 10 Nm
8 Position of front supporting wheel 10 Nm
9 Headland position (rotor front/middle) 10 Nm
10 Headland position (rear rotor) 10 Nm
11 Position of pivoting arm 10 Nm
