KRONE operation terminal Gamma

system, supporting

wheel not extended

Right supporting

wheel not fully

extended

Sensors incorrectly

adjusted, linkage

jammed, incorrectly

connected hydraulic

system, supporting

wheel not extended

Check sensors' adjustment,

lower supporting wheel in

manual mode

Pos: 16.24.76 / BA/Info-Center/Sc hwader/Bedie neinheit - Komf ort/SW 2000/Hau ptmenüs/Alarm meldungen/Logi sche Alarme SW2 000 13 @ 61\mod_12989700 52439_78.doc @ 568776 @ @ 1

Rotors no longer in

float position

Rotors were removed

from the float position

To continue working, return

rotors to the float position

Pos: 16.24.77 / BA/-----Seitenu mbruch------ @ 0\ mod_11961753 11226_0.doc @ 4165 @ @ 1

Table of Contents2
Table of Contents3
Foreword10
Introduction11
- General Description of the Machine11
- Validity11
- Identification Plate11
- Information Required for Questions and Orders12
- Intended Use13
- Road Traffic Regulations and Operating Permits13
- Machine Overview14
- Technical Data15
Safety16
- Identifying Symbols in the Operating Instructions16
- Identification of the Hazard Warnings16
- Safety Instructions and Accident Prevention Regulations18
- Hitched Implements19
- PTO Operation20
- Hydraulic System21
- Tyres21
- Maintenance21
- Unauthorised Conversion/Modification and Spare Parts Production22
- Inadmissible Modes of Operation22
- Position of the Adhesive Safety Stickers on the Machine23
- Introduction23
- Safety Instructions on the Machine23
- Position of the General Information Labels on the Machine26
Commissioning29
- First Installation29
- Fitting the Protective Frames/Hoop Guards on the 6 Rotors30
- Requirements on the Tractor32
- Preparations on Tractor32
  - Adjusting the Lower Suspension Arms32
Table of Contents33
- Electrical Power Supply33
- Mounting Onto the Tractor33
- PTO Shaft34
  - Length Adjustment34
- Height of Tractor Lower Suspension Arms34
KRONE Operation Terminal Gamma35
- Mounting the Control Unit36
  - Electrical Power Supply37
- Overview38
- Description of the Keys39
- Operational Readiness41
- Display Areas on the Screen42
- Road Travel" Basic Screen48
- Basic Screen "Lifting the Rotors49
- Basic Screen "Width Adjustments54
- Basic Screen "Working Height57
  - Adjusting the Working Height of the Rotors57
  - Rotor Height Automatic Mode58
- Menu Level59
  - Short Overview59
  - Bringing up a Menu Level60
- Main Menu 1 - Settings62
- Main Menu 2 - Counters68
  - Menu 2-2 "Total Counters71
- Main Menu 3 „Manual Operation72
- Main Menu 4 - Service79
- Main Menu 5 - Information90
- Main Menu 6 "Technician91
  - Alarm Message92
- Alarm Messages93
Control Unit - Auxiliary Control99
- Mounting100
  - Electrical Power Supply101
- Overview of Auxiliary Control102
- Operational Readiness104
- Lowering the Rotors from Transport to Headland Position105
  - Lowering All Rotors to Headland Position105
- Lowering the Rotors from the Headland Position to the Working Position106
Table of Contents108
- Raising the Rotors from the Working Position to the Headland Position108
- Raising All Rotors from the Headland Position to the Transport Position109
- Adjusting the Working Width110
  - Adjust the Front Working Width110
- Alarm Messages110
- Malfunctions - Causes and Remedies110
KRONE ISOBUS-Terminal CCI 100111
- Installing the Terminal into Cabin112
- ISOBUS Short Cut Button113
- Display Areas on the Screen120
  - Status Line Area (I)121
  - Displays in the Main Window (II)122
- Basic Screen "Width Adjustments125
  - Working Width125
  - Swath Width126
- Basic Screen "Working Height127
  - Adjusting the Working Height of the Rotors127
- Basic Screen „Lifting the Rotors128
- Menu Level135
  - Brief Overview135
  - Calling up the Menu Level136
- Main Menu 1 "Settings137
  - Menu 1-2 "Zero Calibration Rotor Height" (Rotor Height Display Option)138
  - Menu 1-3 "Overlap139
- Main Menu 2 "Counters140
  - Menu 2-1 "Customer Counter141
  - Menu 2-2 "Total Counters144
- Main Menu 3 „Manual Operation145
- Main Menu 4 "Service151
- Main Menu 5 "Information162
- Main Menu 6 „Fitter163
- Main Menu 9 "ISO Settings Info164
  - Menu 9-1 "Softkeys ISO Terminal165
  - Menu 9-2 "Switching between Terminals166
- Alarm Message167
- Alarm Messages168
ISOBUS Operation173
- Attaching the ISOBUS Terminal174
  - Connection Terminal to Tractor174
  - Connection Tractor to Machine174
- Differing Functions to KRONE ISOBUS Terminal CCI175
  - Menu 4-7 "Diagnostics Auxiliary (AUX)176
- Main Menu 9 "ISO Settings Info177
  - Menu 9-1 "Softkeys ISO Terminal178
  - Menu 9-2 "Switching between Terminals179
- ISOBUS „Auxiliary"-Function (AUX)180
  - Example of a Joystick Assignment for Fendt (Default Setting)182
Start-Up183
- Mounting Onto the Tractor183
Table of Contents184
- Hydraulics184
  - Special Safety Instructions184
  - Connecting the Hydraulic Lines185
- Lighting Connection186
- Connecting the Electrical Controls187
- Compressed Air Connections for the Compressed Air Brake188
  - Moving the Machine Without Tractor189
- Hydraulic Brake (Export)189
- Install the PTO Shaft190
- Parking Brake191
Driving and Transport192
Operation193
- Overload Protection193
- From Transport into Working Position194
  - Removing the Tine Guards from the Tine Tips194
- Lowering the Rotor Arms into Working Position194
- Adjusting the Raking Height195
- Auxiliary Steering196
  - Move Auxiliary Steering to Centre Position196
- Travelling on an Incline197
- Travelling Speed und Drive Speed197
- Switching from Working Position to Transport Position198
- Raising the Rotor Arms to Transport Position198
- Protecting the Tine Tips (Transport Position and Swather Switched Off)199
- Parking200
Settings202
- To Adjust the Rotor Running Gear202
- Setting the Lifting Height in Headland Position203
- Adjustable Throttles204
Maintenance205
- Special Safety Instructions205
- Spare Parts205
- Tightening Torques206
- Tightening Torques (Countersunk Screws)207
- Testing the Screws on the Tines207
- Tyres208
  - Checking and Maintaining Tyres208
- Replacing the Tine Arms(in Case of Repair)210
- Position of the Sensors212
  - Adjusting the Sensors214
    - Namur Sensor D = 12 MM214
    - Namur Sensor D = 30 MM214
Maintenance - Hydraulic System215
- Load-Sensing Connection216
- Adjusting the Hydraulic System217
- Emergency Manual Activation217
- Preparing the Machine for Road Travel (in Emergency Manual Mode)219
- Hydraulic System Circuit Diagrams224
- High-Pressure Filter226
Maintenance - Lubrication Chart227
- Special Safety Instructions227
- PTO Shaft227
Maintenance - Lubrication Chart228
- Lubrication Chart228
Maintenance - Gearbox230
- Filling Quantities and Lubrication Designations for Gearboxes230
- Rotor Gear231
- Angular Gearbox231
Maintenance - Brake System232
- Air Filter for Pipe233
- Compressed-Air Reservoir234
Special Equipment235
- Tine Loss Safeguard235
Placing in Storage236
- Special Safety Instructions236
- At the End of the Harvest Season237
- Before the Start of the New Season238
- Special Safety Instructions238
Malfunctions - Causes and Remedies239
- Special Safety Instructions239
- Electrical Circuit Diagram241
