Lattice Semiconductor CertusPro-NX Usage Guide

CertusPro-NX SerDes/PCS Usage Guide
Preliminary Technical Note
166 © 2020-2021 Lattice Semiconductor FPGA-TN-02245-0.81
All rights reserved. CONFIDENTIAL
Table C. 2 shows some potential serial protocol applications based on CertusPro-NX SerDes/PCS.
Table C. 2. Serial Protocol Applications
Protocol
Bit Rate (Gbps)
Reference Clock Available
Coding
SerDes/PCS Mode
PCIe
2.5
83.333, 100, 125
8B/10B
PCIe PCS
5
83.333, 100, 125
8B/10B
PCIe PCS
8
83.333, 100, 125
128B/130B
PCIe PCS
DP
1.62
81, 108, 162
8B/10B
8B/10B PCS
2.7
90, 108, 135
8B/10B
8B/10B PCS
5.4
90, 108, 135
8B/10B
8B/10B PCS
8.1
81, 135
8B/10B
8B/10B PCS
1000BASE-X/ GigE
1.25
83.333, 125
8B/10B
8B/10B PCS
SGMII
1.25
83.333, 125
8B/10B
8B/10B PCS
XAUI
3.125
78.125, 104.166, 156.25
8B/10B
8B/10B PCS
QSGMII
5
83.333, 100, 125
8B/10B
8B/10B PCS
10GBASE-R
10.3125
161.1328125
64B/66B
64B/66B PCS
CoaXPress
1.25
83.333, 125
8B/10B
8B/10B PCS
2.5
83.333, 100, 125
8B/10B
8B/10B PCS
3.125
78.125, 104.166, 156.25
8B/10B
8B/10B PCS
5
83.333, 100, 125
8B/10B
8B/10B PCS
6.25
78.125, 104.166, 156.25
8B/10B
8B/10B PCS
SLVS-EC
1.152
76.8, 115.2
8B/10B
8B/10B PCS
1.188
79.2, 118.8
8B/10B
8B/10B PCS
2.304
76.8, 92.16, 115.2, 153.6
8B/10B
8B/10B PCS
2.376
79.2, 95.04
1
,118.8, 158.4
1
8B/10B
8B/10B PCS
4.608
76.8, 92.16, 115.2, 153.6
8B/10B
8B/10B PCS
4.752
79.2, 95.04
1
,118.8, 158.4
1
8B/10B
8B/10B PCS
Note:
This crystal may not be available.
