Chapter 6 Groups
Page 104 Rev. 1.30.03.07.r1
Recording Groups in the Group Preview
Sub-Display
Recording a channel group blind
Follow the steps below to record a group of conventional channels blind:
Procedure: Notes:
1. Press [PREVIEW]
2. Press (SelGrp) [#] Creates new group
3. Press [ENTER] If group has already been
recorded, its levels will
show.
4. Select channels and set Group recorded
channel levels
All levels are recorded automatically when in a Preview display, it is not
necessary to press the [RECORD GROUP] hard-key.
Recording a device trait group blind
Follow the steps below to record a group of device traits blind:
Procedure: Notes:
1. Press [PREVIEW]
2. Press (SelGrp) [#] Creates new group
3. Press [ENTER]
4. Press [DEVICE] [1] [THRU] [4] [ENTER]
5. Adjust traits using encoder wheels Group recorded
To view additional devices, use the up/down arrow keys to scroll
through devices in device display box. Use the device arrow keys next
to LCD to view additional traits. To de-select a trait so that it will not be
recorded, position the trackball cursor over the trait and press the
[SELECT] key next to the trackball. See
Chapter 10 Automated
Devices
for more information on using automated devices.
