Chapter 1 Introduction
Page 6 Rev. 1.30.03.07.r1
Console Controls
1 2 3 4 5 6 7 8 9 10 11 12 13 14
Figure 1.0 Console
1. Channel Faders and Bump Buttons 8. Trackball Select / Change
Chapter 3
Keys
Page 10
2. Submaster Faders
Chapter 4
9. Trackball
Page 10
3. Submaster Bump Buttons 10. Device Encoder Wheels
Chapter 4 Chapter 10
4. Cue Playback Controls 11. Device Arrow / Shift Keys
Chapter 5 Chapter 10
5. Soft-keys / Macro Keys / Display Keys 12. Grand Master Fader
Page 7 Page 10
6. Data Keypad
Pages 8 - 9
13. Blackout Key
Page 10
7. Arrow Keys
Page 11
14. Device LCD
Chapter 10
