Leviton 600 - Appendix D Resident Devices; Resident Device Types

User Guide Appendix D Resident Devices
Rev. 1.30.03.07.r1 Page 237
Appendix D Resident Devices
Resident Device Types
Software version 1.30 of the control console ships with the following
Automated Lighting Device Definitions resident in memory.
High End Systems Products
AF1000 - Personality DIP switches 3, 4 & 5 on.
CyberLight - Mode 2
CyberLight CX
Intellabeam - Personality switches 3 & 5 on, 8 channels
Intellabeam 16 - Personality switches 3, 5 & 6 on, 10 channels
Studio Color - Version 37a
Studio Spot 250
Studio Spot
Tech no be am
Trackspot - Personality switches 3 & 5 on.
Martin Products
MAC 250 - Mode 4
MAC 300 - Mode 4
MAC 500 - Mode 4
MAC 600 - Mode 4
MAC 1200 - Mode 4
MX 1 - Full DMX mode, 6 channels, channel 2 is not used
Pal 1220 - Version 2 Mode 4 (SPEC\LoFF On)
Pal 1220 E - Version 1 Mode 4
Roboscan Pro 1220 XR - Mode 2
Roboscan Pro 1220 CMYR - Mode 2
Roboscan 518 - Mode 3, Jumper pins 4 & 5 of internal jumper PL432
Roboscan Pro 218- Mode 3
Roboscan Pro 218 - Martin DMX 512 Interface, Mode 11
Roboscan 812 - 7 channel mode, pins 4 & 5 of internal jumper PL11
Robocolor Pro 400 - Version 5
Robocolor - Martin DMX 512 Interface, Mode 2, Switch 2 down
Robocolor II - Martin DMX 512 Interface, Mode 3, Switches 1 & 2 down
Robocolor III
RoboZap - Mode 15, Switches 1, 2, 3 and 4 down
