User Guide Chapter 14 Alternate Control Interfaces
Rev. 1.30.03.07.r1 Page 215
DMX IN
The DMX512 IN feature of the console merges incoming dimmer levels from
another console with those of the DMX512 Output B of the console in a
HTP fashion.
The DMX512 IN connector is a 5 pin male XLR and is located at the rear of
the console.
Remote Macro Activation
Macros recorded in macro keys M1 - M8 may be fired externally. If a
contact is made between pin 9 and any of pins 1 - 8 of the macro connector
on the back of the console, the macro corresponding to the diagram below
will fire. The macro will fire at the instant the contact is closed and will not
fire again until the contact is opened and closed again.
The connector at the rear of the console is 9 pin D type.
Pinout
Pin Description
1 Macro Trigger 1
2 Macro Trigger 2
3 Macro Trigger 3
4 Macro Trigger 4
5 Macro Trigger 5
6 Macro Trigger 6
7 Macro Trigger 7
8 Macro Trigger 8
9 Common
