User Guide Chapter 6 Groups
Rev. 1.30.03.07.r1 Page
Editing Groups in the Group Preview
Sub-Display
To select a specific group for viewing and editing press the (SelGrp) soft-
key while in the Preview display. Only one group’s channel or trait
information is shown at a time. Use the left/right arrow keys to view
additional groups.
Editing a channel group blind
Follow these steps to blind edit a previously recorded group:
Procedure: Notes:
1. Press [PREVIEW]
2. Press (SelGrp) [#] [ENTER] Selects group
3. Select channels and set Group recorded
new channel levels
Editing a device trait group blind
Follow the steps below to edit a group of device traits blind:
Procedure: Notes:
1. Press [PREVIEW]
2. Press (SelGrp) [#] [ENTER]
3. Press [DEVICE] [1] [THRU] [4] Select the devices to be
edited by using the device
4. Press [ENTER] key on keypad.
5. Adjust traits using encoder wheels Changes are recorded
automatically in a blind display
To view additional devices use the up/down arrow keys to scroll
through devices in device display box. Use the device arrow keys next
to LCD to view additional traits.To de-select a trait so that it will not be
recorded, position the trackball cursor over the trait and press the
[SELECT] key next to the trackball.
