Leviton 600 - Installing a Keyboard; Installing a Printer

Appendix A Installation
Page 224 Rev. 1.30.03.07.r1
Installing a Keyboard
You can use an optional keyboard to assign names to different features of
your shows, such as to name the show and the cues, submasters, groups,
etc.
CAUTION! Do not connect or disconnect a keyboard while
your console is turned on.
To install an alphanumeric keyboard:
1. Insert the keyboard cable into the connector labeled Keyboard on the
rear of the console (connector is a DIN 5-pin).
Installing a Printer
CAUTION! Do not connect or disconnect a printer while your
console is turned on.
To install a printer:
1. Insert the printer cable into the parallel printer connector labeled Printer
on the rear of the console (connector is a 25 pin D type).
